SPL Parts GR86 / BRZ Adjustable Front Sway Bar Endlinks — Standard
SPL Parts GR86 / BRZ Adjustable Front Sway Bar Endlinks — Standard is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
SPL Parts GR86 / BRZ Adjustable Front Sway Bar Endlinks — Standard (SPL FE FRS) is designed for front sway bar preload adjustment on the listed Toyota GR86 / GT86 / Scion FR-S / Subaru BRZ applications.
Standard-length adjustable front sway bar endlinks allow preload and bar-angle setup on the listed 86/BRZ platform without selecting the shorter FES version by mistake.
Specifications and fitment
| Brand | SPL Parts |
|---|---|
| Manufacturer part number | SPL FE FRS |
| Application | Toyota GR86 / GT86 / Scion FR-S / Subaru BRZ |
| Function | Front sway bar preload adjustment |
| Supplied as | Pair |
| Mounting-point distance | 232–271mm / 9.15–10.65 inches |
Setup and ordering notes
Standard-length version: 232–271mm (9.15–10.65 inches) between mounting points. For modified setups requiring 188–226mm, use the separately listed SPL FES FRS short version.
Product FAQs
How do adjustable sway bar endlinks differ from a sway bar?
The endlinks connect the sway bar to the suspension. Adjusting their length helps set bar position and remove unwanted preload; the links do not replace the bar or directly change its diameter.
Should I choose standard or short front endlinks for my GR86 / BRZ?
SPL FE FRS covers 232–271mm between mounting points. SPL FES FRS is the shorter 188–226mm option for modified mounting geometry or clearance needs. Measure the installed setup; coilovers alone do not automatically determine which version is correct.
What should a street-car owner know about NVH?
Replacing compliant factory mounts or bushings with a more rigid connection can transmit more road noise or impacts. SPL identifies an NVH tradeoff for this part; consider it when choosing components for a daily-driven car.
Explore related SPL components
- SPL Parts Toyota/Subaru GR86/BRZ/GT86/FR-S Front Lower Control Arms
- SPL Parts GR86/BRZ/GT86/WRX Rear Lower Camber Arms
Pit Garage is an automotive service and performance parts shop in the Los Angeles area. Contact us with your chassis, drivetrain, ride height and installed suspension if you need help selecting the correct SPL part.
