SPL Parts Toyota GR86 / Subaru BRZ Adjustable Rear Sway Bar Endlinks
SPL Parts Toyota GR86 / Subaru BRZ Adjustable Rear Sway Bar Endlinks is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
SPL Parts Toyota GR86 / Subaru BRZ Adjustable Rear Sway Bar Endlinks (SPL RE FRS) is designed for rear sway bar preload adjustment on the listed Toyota GR86 / GT86 / Scion FR-S / Subaru BRZ applications.
Compact rear adjustable sway bar links use PTFE-lined FK bearings and high-misalignment studs. Link length must suit the rear lower arm mounting position.
Specifications and fitment
| Brand | SPL Parts |
|---|---|
| Manufacturer part number | SPL RE FRS |
| Application | Toyota GR86 / GT86 / Scion FR-S / Subaru BRZ |
| Function | Rear sway bar preload adjustment |
| Supplied as | Pair |
| Mounting-point distance | 88–100mm / 3.5–4.0 inches |
Setup and ordering notes
Adjustment range is 88–100mm (3.5–4.0 inches) between mounting centers. Very low ride heights or non-SPL rear lower arms can require a different length or bar mounting position.
Product FAQs
How do adjustable sway bar endlinks differ from a sway bar?
The endlinks connect the sway bar to the suspension. Adjusting their length helps set bar position and remove unwanted preload; the links do not replace the bar or directly change its diameter.
What rear endlink length does SPL RE FRS cover?
The listed center-to-center range is 88–100mm. Check the installed rear lower arm and sway bar mounting positions, especially with a low ride height or non-SPL lower arms.
What should a street-car owner know about NVH?
Replacing compliant factory mounts or bushings with a more rigid connection can transmit more road noise or impacts. SPL identifies an NVH tradeoff for this part; consider it when choosing components for a daily-driven car.
Explore related SPL components
- SPL Parts Toyota/Subaru GR86/BRZ/GT86/FR-S Front Lower Control Arms
- SPL Parts GR86/BRZ/GT86/WRX Rear Lower Camber Arms
Pit Garage is an automotive service and performance parts shop in the Los Angeles area. Contact us with your chassis, drivetrain, ride height and installed suspension if you need help selecting the correct SPL part.
